| CLASSIFICATION | UNIT | DX55-5B |
|---|---|---|
| Operating weight | Ton | 5.55 |
| Bucket Capacity (SAE) | m3 | 0.18~0.21 m³ |
| Engine Power (SAE j1349, net) | kgf.m/rpm | 35/2,100 |
| Engine Model | - | 4TNV94L-BVDBC |
| Travel Speed (High/Low) | km/h | 2.3/4.1 |
| Max. Digging Reach | mm | 6,135 |
| Max. Digging Depth | mm | 3,800 |
| Max. Digging Height | mm | 5,795 |
| Overall Length | mm | 5,850 |
| Overall Width | mm | 1,860 |
| Overall Width | mm | 1920 |
| Overall Height | mm | 2,580 |
