| CLASSIFICATION | UNIT | DX1000LC-7 |
|---|---|---|
| Operating weight | Ton | 97.0~99.5 |
| Bucket Capacity (SAE HEAPED) | m3 | 5.4~6.8 |
| Engine Rated Power (SAE j1349, net) | kW/rpm | 470/2,100 |
| Engine Model | - | Perkins 2806D |
| Travel Speed | km/h | 4.5/2.6 |
| Max. Digging Reach | mm | 12,430 |
| Max. Digging Depth | mm | 7,260 |
| Max. Digging Height | mm | 12,425 |
| Overall Length | mm | 13,800 |
| Overall Width | mm | 3,440 |
| Overall Height | mm | 5,090 |
