| CLASSIFICATION | UNIT | DX450LC-7M |
|---|---|---|
| Operating weight | Ton | 44.4 |
| Bucket Capacity (SAE HEAPED) | m3 | 1.44~2.16 |
| Engine Rated Power (SAE j1349, net) | kW/rpm | 251.5/1,800 |
| Engine Model | - | SCANIA DC13 076A |
| Travel Speed | km/h | 5.3/3.2 |
| Max. Digging Reach | mm | 11,430 |
| Max. Digging Depth | mm | 7,635 |
| Max. Digging Height | mm | 10,615 |
| Overall Length | mm | 11,740 |
| Overall Width | mm | 3,350 |
| Overall Height | mm | 3,465 |
