| CLASSIFICATION | UNIT | DX800LC-7B |
|---|---|---|
| Operating weight | Ton | 79.5 |
| Bucket Capacity (SAE HEAPED) | m3 | 4.6 |
| Engine Rated Power (SAE j1349, net) | kW/rpm | 403-1800 (SAE J1995) |
| Engine Model | - | Perkins 2506J |
| Travel Speed | km/h | 2.9-4.8 |
| Max. Digging Reach | mm | 12672 |
| Max. Digging Depth | mm | 6,755 |
| Max. Digging Height | mm | 11910 |
| Overall Length | mm | 13370 |
| Overall Width | mm | 4000 |
| Overall Height | mm | 4690 |
