| CLASSIFICATION | UNIT | DL550 |
|---|---|---|
| Operating weight | Ton | 31.1 |
| Bucket Capacity (SAE) | m3 | 5.4 |
| Engine Max. Power (Gross) | kW(HP) / rpm | 294(394) / 2100 |
| Engine Max. Toque (Gross) | N.m / rpm | 2157 / 1200 |
| Travel Speed Forward(1 / 2 / 3 / 4) | km / h | 6.5 / 12.4 / 19.7 / 28 / 36(5th) |
| Travel Speed Reverse(1 / 2 / 3) | km / h | 6.5 / 12.1 / 19 |
| Front Speed (Raise / Dump / Lower) | sec | 6.1 / 1.1 / 4.2 |
| Dump Height at 45Deg | mm | 3285 |
| Breakout Force | kN | 260 |
| Turning Radius at Tire Center | mm | 6,037 |
| Dump Reach at 45Deg | mm | 1535 |
| Tires | - | 29.5-25-22PR(L3) |
| Overall Length | mm | 9525 |
| Overall Width | mm | 3400 |
| Overall Height | mm | 3800 |
