| CLASSIFICATION | UNIT | SD300H |
|---|---|---|
| Operating weight | Ton | 16.8 |
| Bucket Capacity (SAE) | m3 | 2.7 |
| Engine Max. Power (Gross) | kW(HP) / rpm | 220(162)/2000 |
| Engine Max. Toque (Gross) | N.m / rpm | 980/1300~1500 |
| Travel Speed | km / h | 0~36.5 |
| Dump Height at 45Deg | mm | 3,080 |
| Breakout Force | kN | 16.8 |
| Turning Radius at Tire Center | mm | 6,037 |
| Dump Reach at 45Deg | mm | 1,290 |
| Tires | - | 23.5-25-16PR |
| Overall Length | mm | 8,020 |
| Overall Width | mm | 2,992 |
| Overall Height | mm | 3,450 |
