| CLASSIFICATION | UNIT | SD310 |
|---|---|---|
| Operating weight | Ton | 17.3 |
| Bucket Capacity (SAE) | m3 | 3 |
| Engine Max. Power (Gross) | kW(HP) / rpm | 160(217) / 2000 |
| Engine Max. Toque (Gross) | N.m / rpm | 902 / 1300 ~ 1500 |
| Travel Speed | km / h | 0 ~ 38 |
| Dump Height at 45Deg | mm | 3085 |
| Breakout Force | kN | 16.2 |
| Turning Radius at Tire Center | mm | 6,037 |
| Dump Reach at 45Deg | mm | 1297 |
| Tires | - | 23.5-25-16PR |
| Overall Length | mm | 8260 |
| Overall Width | mm | 2992 |
| Overall Height | mm | 3450 |
