CLASSIFICATION | UNIT | SD380 |
---|---|---|
Operating weight | Ton | 19 |
Bucket Capacity (SAE) | m3 | 3.7 |
Engine Rated Power (SAE j1349, net) | kW/rpm | 178 |
Engine Model | - | WD10G240E343 |
Height at Bucket Pivot Point | mm | 4,316 |
Breakout Force | kN | 18.7 |
Turning Radius at Tire Center | mm | 6,058 |
Tires | (l3) | 23.5-25-20 PR |
Overall Length | mm | 8,434 |
Overall Width | mm | 3,026 |
Overall Height | mm | 3,450 |
Static Tipping Load(straight) | kg | 14,800 |
